Best 18V Battery Platform Right Angle Drills

TL;DR: The Ryobi ONE+ HP Right Angle Drill packs a brushless motor, 350 in‑lb of torque and a 3.6‑in. head into a 2.84‑lb, 292 mm‑tall package for tight‑space jobs at a budget‑friendly price.

What really sets this drill apart is its ultra‑compact head length of 3.6 in., letting you reach into cramped cavities where a bulkier tool would miss. A brushless motor delivers up to 350 in‑lb of torque—about twice the torque of the prior model—while the dual‑speed selector offers a low range of 0‑450 RPM and a high range of 0‑1,700 RPM for versatile drilling and fastening.

Compared with the eight other right‑angle drills in this roundup, the Ryobi is among the lightest at 2.84 lb and one of the shortest, with a height of 292 mm. It sits in a similar price tier to the RIDGID sub‑compact, yet it’s lighter than the Metabo HPT model and more compact than the Milwaukee C18RAD‑0. While some competitors ship with integrated lights, this Ryobi foregoes onboard illumination, keeping the design simple and cost‑effective.

Professional reviewers praise the drill’s compactness and the 2× torque boost, noting it shines in overhead or tight‑area applications. Users echo this sentiment, highlighting how the keyless 3/8‑in. chuck speeds up bit changes. The main criticism is the lack of built‑in LED lighting, which can be a drawback in dim workspaces, and the modest two‑speed range may feel limiting for users who prefer finer speed control. At 2.84 lb, the tool is still light enough for most tasks, though a few reviewers mention it can become noticeable during prolonged overhead use.

Best for: Budget‑conscious buyers seeking a reliable entry‑level option — the RYOBI ONE+ HP Right Angle Drill offers Height: 292 mm

Avoid if: You need advanced features or professional‑grade performance

TL;DR: The Einhell TE‑AD 18 Li‑Solo packs 45 Nm of torque, a 1,100 rpm motor and a slim 12.87‑in body into a 2.69‑lb cordless drill that shines in tight‑space DIY jobs.

This right‑angle drill’s standout spec is its 45 Nm maximum torque combined with a 1,100 rpm no‑load speed, all driven by an 18 V fan‑cooled motor. The soft‑grip handle and 10 mm keyless chuck make bit changes quick, while the integrated LED with a 10‑second afterglow lights dark corners. At 12.87 in overall length, 3.35 in width and a weight of just 2.69 lb, it feels light enough to hold overhead for extended periods.

Compared with the other eight tools in our roundup, the Einhell sits in the middle of the weight range: it’s lighter than the Metabo HPT (3.54 lb) and Makita XAD02Z (3.0 lb), but heavier than the RIDGID (2.5 lb) and the ultra‑light Milwaukee C18RAD‑0 (0.0022 lb) listed in the specs. Its torque of 45 Nm trails the Metabo’s 1,200 in‑lb figure and the Milwaukee C18RAD‑0’s 125 in‑lb, yet it outpaces the RYOBI ONE+ HP (which lists a “2X more torque” claim without a numeric value) and the RIDGID’s 375 in‑lb. Speedwise, the Einhell’s 1,100 rpm is lower than Metabo’s 1,800 rpm and Makita XAD02Z’s 1,800 rpm, but still adequate for most DIY screwing and drilling tasks.

Reviewers consistently praise the angled, slim design for reaching into cabinets, under‑sink spaces and other confined areas. Professional reviewers highlight the all‑metal transmission as a durability boost, noting that the metal gears help transfer power efficiently. Users who already own Einhell Power X‑Change batteries appreciate the rotatable battery holder, though the lack of an included battery or charger is a frequent complaint. The single torque setting and single‑speed gear are seen as a limitation for heavy‑duty work, but most DIY enthusiasts find the tool’s performance more than sufficient.

Best for: Entry-level buyers or those on a tight budget — the Einhell TE‑AD 18 Li‑Solo offers Depth: 327 mm

Avoid if: You want the best value-per-dollar in its price range

TL;DR: The Makita XAD02Z packs 121 in‑lbs of torque, a 0‑1,800 RPM variable speed range, and a 12.87‑in overall length into a 3‑lb, 18 V cordless right‑angle drill that balances power and portability.

What really stands out is the 121 in‑lbs of maximum torque paired with a 0‑1,800 RPM no‑load speed, giving you enough bite for most residential drilling and driving tasks. At 3.0 lb and a 12.87‑in overall length, the tool feels light enough to swing into tight spots, while the 89 mm angle‑head height lets the chuck clear obstacles that a straight drill can’t reach. The 3/8‑in keyless chuck and reversible drive add convenience for quick bit changes and reverse drilling.

Compared with the other eight drills in this roundup, the XAD02Z is lighter than the Metabo HPT DN18DSLQ4 (3.54 lb) and the Milwaukee M18 FUEL Super Hawg, but heavier than the Milwaukee C18RAD‑0 (2.75 lb) and the RIDGID SubCompact (2 lb). Its torque sits well below the Metabo HPT’s 1,200 in‑lbs and the RIDGID’s 375 in‑lbs, yet it outpaces the Milwaukee C18RAD‑0’s 125 in‑lbs and the Einhell’s modest torque figure. Speed‑wise, Makita matches the Metabo HPT’s 0‑1,800 RPM range and exceeds the Milwaukee C18RAD‑0’s 0‑1,500 RPM, though it falls short of the RIDGID’s 0‑1,900 RPM top end.

Professional reviewers praise the high torque and variable speed for precise control, especially in confined spaces where the 12.87‑in reach shines. Users also note the lightweight feel and the handy star‑protection system that guards against overload, over‑discharge, and overheating. On the downside, the brushed‑motor design may not last as long as brushless rivals, and the 3/8‑in steel drilling capacity limits heavy‑duty metal work. Finally, the tool‑only configuration means you’ll need to buy an 18 V battery and charger separately.

Best for: Most users seeking a balanced, mainstream option — the Makita XAD02Z offers Angle Head Height: 89 mm

Avoid if: You need heavy‑duty steel drilling, prefer a battery‑included kit, or require the highest torque available.

TL;DR: The Milwaukee M18 FUEL Super Hawg packs a 0‑1550 RPM brushless motor, a 1/2‑in keyed chuck and LED light into a 12.5‑lb, 22‑in long cordless right‑angle drill that rivals corded performance.

The standout spec is its high‑speed range of 0‑1550 RPM, which professional reviewers say matches the power of a corded drill for rough‑in plumbing and HVAC jobs. Coupled with a 1/2‑in all‑metal keyed chuck, the tool can drill up to 100 holes of 2‑9/16 in. in 2× lumber and bore 6‑1/4 in. holes in beams—numbers that set it apart from many competitors.

Compared with the other eight drills in this roundup, the Super Hawg is noticeably heavier than the lightweight Metabo HPT DN18DSLQ4 (which weighs about 3.5 lb) and the compact RIDGID 18V SubCompact (around 2 lb). It is also longer than the Makita XAD06Z’s 17‑1/8 in. overall length, giving it more leverage in tight spaces. Its 1/2‑in chuck is larger than the 7/16‑in chuck on the Makita XAD06Z and the 3/8‑in chucks on the Bosch GRD18V‑127 and Metabo HPT, allowing it to accept bigger bits.

User sentiment highlights the smooth dual‑speed trigger and bright LED lighting as real‑world conveniences, while the mechanical clutch is praised for preventing bind‑up when drilling in confined areas. Professional reviewers note that the brushless motor and REDLINK PLUS intelligence provide corded‑equivalent reliability, but they also point out that you’ll need a high‑output M18 battery—sold separately—to unlock the tool’s full potential.

Best for: Those prioritizing quality and willing to pay for premium performance — the Milwaukee M18 FUEL Super Hawg offers Chuck Size: 1/2 in.

TL;DR: The Metabo HPT DN18DSLQ4 packs a 3.5‑inch head, 1,200 in‑lb torque and 0‑1,800 RPM speed into a 3.54‑lb cordless drill, making tight‑space work fast and comfortable for DIY pros.

What really sets this drill apart is its 3.5‑inch right‑angle head combined with a 0‑1,800 RPM variable speed range. At 3.54 lb, it feels light enough for overhead jobs yet solid enough to handle the 1,200 in‑lb torque rating without wobble. The 3/8‑inch keyless chuck and built‑in LED light let you swap bits quickly and see into dark cavities.

Compared with the eight other right‑angle drills in this roundup, the DN18DSLQ4 sits toward the heavier end—still lighter than the bulkier Makita XAD06Z—but it offers more torque than many entry‑level models such as the Einhell TE‑AD 18 Li‑Solo. Its side‑handle design isn’t listed for the RIDGID 18V SubCompact, giving you extra leverage when drilling in cramped spots. While the Milwaukee C18RAD‑0 and RYOBI ONE+ HP models feature multiple clutch settings, Metabo provides a single clutch, which keeps the interface simple but may limit fine‑tuning for delicate fasteners.

Professional reviewers praise the compact head for reaching between joists and behind pipes, and they note the variable trigger delivers precise speed control for both delicate and aggressive tasks. Users also appreciate the keyless chuck that tightens without spinning the spindle, and the LED job light that brightens shadowy work zones. The main criticisms focus on the brushed motor, which can wear faster under heavy use, and the 3/8‑inch chuck that restricts larger drill‑bit compatibility. Only one clutch setting is available, which some users find limiting for very light fastening.

Best for: Value-conscious buyers seeking quality at $139.00 — the Metabo HPT DN18DSLQ4 offers Chuck Size: 3/8 inch

Avoid if: You need brushless durability for heavy demolition or require a larger chuck for big‑diameter bits.

TL;DR: The Milwaukee C18RAD-0 packs a 12‑position electronic clutch, 125 ft‑lb of torque and a 3.75‑inch head into a 2.75‑lb, 18‑V cordless drill, making tight‑space work powerful yet portable.

The standout feature is the electronic clutch with 11 torque settings plus a drill mode, giving you 12 precise positions for fastening. Combined with a 3.75‑inch head length, the tool can reach into cramped cavities that larger drills can’t. It delivers 125 ft‑lb of torque and a no‑load speed range of 0‑1500 RPM, all while weighing just 2.75 lb and running on an 18 V battery system.

At 2.75 lb, the C18RAD‑0 is lighter than the Makita XAD02Z (3.0 lb) and the Metabo HPT DN18DSLQ4 (3.54 lb) but a touch heavier than the RIDGID SubCompact (2.5 lb). Its 0‑1500 RPM no‑load speed is slower than the 0‑1,800 RPM offered by both the Makita XAD02Z and the Metabo HPT, so it isn’t the fastest in the lineup. Compared with the bulkier Makita XAD06Z (7.3 lb) and the Bosch GRD18V‑127 (6.8 lb), Milwaukee’s drill feels notably more compact and easier to maneuver.

Users consistently praise how the compact head fits into tight spots on HVAC ductwork and electrical panels, and the built‑in LED with clutch‑position indicator is highlighted as a real time‑saver. However, several reviews warn that the high torque can strip Phillips‑head screws if the lowest setting isn’t chosen carefully, and the 2.75‑lb weight can become tiring during prolonged overhead jobs, especially with larger battery packs.

Additional technical touches include a 3/8‑inch keyless/ratcheting chuck, paddle‑style switch, reversible drive, and Milwaukee’s REDLINK overload protection. The tool comes with a five‑year warranty, reinforcing its professional‑grade positioning within the M18 ecosystem.

Best for: Professionals who need precise torque control in cramped areas — the Milwaukee C18RAD-0 offers Clutch Settings: 11 torque settings + 1 drill mode.

TL;DR: The RIDGID 18V SubCompact Right Angle Drill packs a 3.5‑inch head, 2 lb weight and 375 in‑lb torque into an $87.50 cordless tool, ideal for tight‑space DIY work.

What really sets this drill apart is its 3.5‑inch head length, the shortest among the nine right‑angle drills in our roundup. Combined with a bare‑tool weight of 2 lb, it slides into cavities between studs or inside cabinets where larger heads simply won’t fit. The brushless 18 V motor spins up to 1,900 RPM on the high‑speed setting, delivering a maximum torque of 375 in‑lb despite the tiny package.

Compared with its peers, the RIDGID is lighter than the Metabo HPT (3.54 lb) and the Einhell (≈2.69 lb) while offering a more compact head than the Milwaukee C18RAD (3.75 in head) and the Metabo HPT (4.45 in head). Its overall length of 11.0 in and width of 3.23 in keep it short enough to maneuver in cramped spots, whereas the Makita XAD06Z stretches to over 17 in in length. The tool‑only configuration means you’ll need an existing RIDGID 18 V battery, a trade‑off that some competitors avoid by bundling a battery.

Everyday users consistently praise the drill’s maneuverability for plumbing, electrical and cabinet installations. Reviewers highlight the built‑in LED work light and on‑board bit storage as handy touches that keep the job site tidy. A few owners note occasional chuck slippage with larger bits and mention that the 3/8‑inch chuck limits the size of bits they can run, especially when tackling tougher materials.

Technical details reinforce its niche appeal: a keyless 3/8‑inch chuck accepts 1/4‑inch hex‑drive bits up to 2 in long, and the pistol‑style handle provides a comfortable grip for extended use. The drill offers two speed settings (low 0‑500 RPM, high 0‑1,900 RPM) and full reversibility, making it versatile for both drilling and screw‑driving in confined areas.

Best for: Entry-level buyers or those on a tight budget — the RIDGID 18V SubCompact Right Angle Drill offers Chuck Size: 3/8 inch

Avoid if: You need powerful performance or professional‑grade features

TL;DR: The Makita XAD06Z packs a brushless 18 V motor, 7/16‑inch hex chuck and dual LED lights into a slim 4.76‑inch head, delivering professional‑grade torque for tight‑space work at a premium price.

This right‑angle drill’s standout spec is its 7/16‑inch hex chuck paired with a brushless motor that reaches up to 1,400 RPM on the high‑speed setting. At 7.3 lb (7.28 lb net) it stays light enough for overhead jobs, while the 4.76‑inch head height lets you reach into cramped cavities that larger tools can’t access. The built‑in dual LED lights offer pre‑glow and afterglow, so you can see your work even in dark conduit runs.

Compared with the eight other drills in this roundup, the Makita is heavier than the Metabo HPT DN18DSLQ4’s 3.54 lb frame but lighter than Milwaukee’s M18 FUEL Super Hawg, which tips the scales at 12.5 lb. Its 7/16‑inch chuck is smaller than the 1/2‑inch chucks found on Bosch and Milwaukee models, meaning you’ll need the right‑size bits for larger holes. The dual‑light setup gives it more illumination than the single‑LED RYOBI or the integrated glow on the Einhell, while the side‑handle design adds flexibility that the compact RYOBI and RIDGID tools lack.

User feedback praises the brushless motor for delivering “superior cordless speed” and the slim barrel for easy access in electrical and plumbing applications. Reviewers also note the electric brake as a handy feature for quick stop‑and‑go work. On the downside, the tool is sold without a battery or charger, so you’ll need to buy Makita’s LXT 18 V pack separately. The 7/16‑inch chuck can feel restrictive for users who rely on larger round‑shank bits, and the 4.2‑star rating indicates some buyers have been less satisfied than with competing models.

Technically, the XAD06Z offers a two‑speed transmission (0‑450 RPM low, 0‑1,400 RPM high) and reversible operation, making it versatile for both drilling and driving. It can punch up to 200 holes of 7/8‑inch diameter per charge on a 5.0 Ah pack, according to manufacturer claims, and it handles 5‑inch hole‑saw cuts in wood. The 18 V brushless motor, combined with a metal gear housing, promises durability for demanding trade work, and Makita backs the unit with a three‑year limited warranty.

Best for: Those prioritizing quality and willing to pay for premium performance — the Makita XAD06Z offers Chuck Size: 7/16 inch

Avoid if: Reliability and user satisfaction are your top concerns

TL;DR: The Bosch GRD18V-127 packs a 70 Nm brushless motor, 1/2‑inch keyed chuck and dual‑mode KickBack Control into a 6.8‑lb right‑angle drill that excels in tight‑space, high‑torque jobs.

What really sets this tool apart is its 70 Nm of soft torque combined with a 127 mm (5 in) hole‑saw capacity, letting you tackle large‑diameter holes without swapping tools. The brushless motor runs at up to 1,800 RPM on the high‑speed setting and drops to 550 RPM for low‑speed control, while the keyed 1/2‑inch chuck gives you a solid grip on big bits.

Compared with the eight other drills in our roundup, the Bosch sits in the middle of the weight range – lighter than the Milwaukee M18 Super Hawg’s 12.5 lb heft but heavier than the Metabo HPT DN18DSLQ4’s 3.54 lb frame and the RYOBI ONE+ HP’s 2.84 lb unit. Its chuck size of 1/2 inch is larger than the 7/16‑inch or 3/8‑inch chucks found on several peers, giving you more bit‑capacity out of the box. Speed-wise, the 1,800 RPM top end matches the Makita XAD02Z’s 0‑1,800 RPM range and exceeds the Milwaukee M18’s 0‑1,550 RPM, while the low‑speed 550 RPM still outpaces the RIDGID’s 0‑500 RPM low setting.

Professional reviewers praise the dual KickBack Control, noting its fast and slow modes help prevent injury if the bit binds. Users also highlight the 5‑inch hole‑saw capacity as a clear advantage for rough‑in work. The downside that pops up is the keyed chuck, which requires a separate key and slows bit changes compared with quick‑change designs. And because the tool is sold as a bare unit, you’ll need to supply your own compatible 18 V battery and charger.

Best for: Those prioritizing quality and willing to pay for premium performance — the Bosch GRD18V-127 offers Chuck Size: 1/2 inch

Avoid if: You need advanced features or professional‑grade performance
