Tenda TEG1016D — Review & Specs | Pricepect | Pricepect

Home Network HubsTenda TEG1016D

Tenda TEG1016D — image 1

Tenda

Tenda TEG1016D

Expert Review Analysis

The Tenda TEG1016D is a 16‑port unmanaged Gigabit Ethernet switch built for video‑surveillance, offices, and SMEs. It offers plug‑and‑play setup, fanless silent operation, 6 kV lightning protection, and a compact 1U form factor with 32 Gbps switching capacity.

✓ Best for: Small‑to‑medium businesses, offices, workgroups, and video‑surveillance installations that need a simple, silent, and surge‑protected 16‑port Gigabit switch.✗ Not ideal for: Environments that require managed features like VLANs, QoS, PoE, or frequent firmware upgrades, such as larger enterprises or advanced networking setups.

Pros

✓Provides 6 kV lightning protection on all ports and power supply, safeguarding against surges in surveillance environments.
✓Fanless steel housing delivers silent operation and reliable 24/7 connectivity for noise‑sensitive office spaces.
✓Plug‑and‑play auto‑negotiation with 16 Gigabit ports enables line‑speed forwarding up to 32 Gbps for large file transfers and video streams.

Price History

Current

$54.99

Average

$51.78

Lowest

$34.99

Highest

$133.97

Price trend (90d):0.0%

Best Seller Rank History

Now#1,041Best#40Worst#1,208 -793

Lower = better sales rank

Rating Trend

Rating4.7/ 5Reviews1,180+-1,659 reviews +0.11

Specifications

Accessories

Package ContentsSwitch, power cord/adapter, quick installation guide/user guide (rack ears may be separate)

Design

Height254 mm mm

Width93 mm mm

Depth345 mm mm

Fanless DesignYes

Housing MaterialFull steel with ventilation holes

Features

Plug & PlayYes

LED Indicators1 Power, 16 Link/Act

Flow ControlIEEE 802.3X

Auto MDI/MDIXSupported

General

BrandTenda

ModelTEG1016D

ColorCurry

Release Date2023-08-20

Warranty3 years

Network

StandardsIEEE 802.3, 802.3u, 802.3x, 802.3ab

Transmission Media10Base-T: Cat 3 UTP or better; 100Base-TX: Cat 5 UTP or better; 1000Base-T: Cat 5e UTP or better

CertificationsCE, FCC, RoHS

Performance

Switching Capacity32 Gbps Gbps

Buffer Size2M

MAC Address Table8K entries

Transmission MethodStore-and-forward

Forwarding Rate (10 Mbps)14,880 pps pps

Ports

Number of Ports16 ports

Port Speed10/100/1000 Mbps auto-negotiation

Power

Power Supply InputAC 100-240V, 50/60 Hz

Power Consumption12W (max at 220V) W

Lightning Protection (Ports)6 kV common mode

Lightning Protection (Power Supply)6 kV common mode / 4 kV differential mode

Protection

Lightning Protection6 kV common mode on ports; 6 kV common/4 kV differential on power supply

Dimensions & Weight

Height10.0 inches

Width3.66 inches

Depth13.58 Inches

Research Sources

primuscable.com

Similar Products

NETGEAR 5-Port Gigabit Ethernet Unmanaged Switch (GS105NA) - Desktop or Wall Mount, and Limited Lifetime Protection

NETGEAR 5-Port Gigabit Ethernet Unmanaged Switch (GS105NA) - Desktop or Wall Mount, and Limited Lifetime Protection

NETGEAR

NETGEAR 16-Port Gigabit Ethernet Unmanaged Switch (GS116NA) - Desktop or Wall Mount, and Limited Lifetime Protection

NETGEAR 16-Port Gigabit Ethernet Unmanaged Switch (GS116NA) - Desktop or Wall Mount, and Limited Lifetime Protection

NETGEAR 16-Port Gigabit Ethernet Unmanaged Switch (JGS516) - Desktop or Rackmount, and Limited Lifetime Protection

NETGEAR 16-Port Gigabit Ethernet Unmanaged Switch (JGS516) - Desktop or Rackmount, and Limited Lifetime Protection

NETGEAR

NETGEAR 24-Port Gigabit Ethernet Unmanaged Switch (JGS524) - Desktop or Rackmount, and Limited Lifetime Protection

NETGEAR 24-Port Gigabit Ethernet Unmanaged Switch (JGS524) - Desktop or Rackmount, and Limited Lifetime Protection

NETGEAR

CyberPower CPS1215RMS Surge Protector, 120V/15A, 12 Outlets, 15 ft Power Cord, 1U Rackmount

CyberPower CPS1215RMS Surge Protector, 120V/15A, 12 Outlets, 15 ft Power Cord, 1U Rackmount

CyberPower

D-Link Ethernet Switch, 16 Port Gigabit Unmanaged Fanless Network Hub Desktop or Rack Mountable (DGS-1016D)

D-Link Ethernet Switch, 16 Port Gigabit Unmanaged Fanless Network Hub Desktop or Rack Mountable (DGS-1016D)

D-Link

Learning Resources TL-SF1005D TP-Link 5-Port Fast Ethernet Unmanaged Switch | Plug and Play | Desktop

Learning Resources TL-SF1005D TP-Link 5-Port Fast Ethernet Unmanaged Switch | Plug and Play | Desktop

TP-Link

StarTech.com 6U Wall Mount Network Rack - 14 Inch Deep (Low Profile) - 19" Patch Panel Bracket for Shallow Server and IT Equipment, Network Switches - 44lbs/20kg Weight Capacity, Black (WALLMOUNT6)

StarTech.com

TRENDnet 8-Port Mini Gigabit Switch, TEG-S80g, Ethernet Splitter, NDAA + TAA Compliant, Desktop Metal Ethernet Network Switch, 8 x Gigabit Ports, Fanless, Lifetime Protection, Black

TRENDnet 8-Port Mini Gigabit Switch, TEG-S80g, Ethernet Splitter, NDAA + TAA Compliant, Desktop Metal Ethernet Network Switch, 8 x Gigabit Ports, Fanless, Lifetime Protection, Black

TRENDnet

Eaton 10250T1323 Selector Switch With Cap, 30mm, 3 Positions, Knob Selector Type

Tenda TEG1016G, 16 Port Gigabit Switch, Unmanaged Rackmount Ethernet Switch with Traffic Optimization, Plug & Play, Fanless Quiet & Metal Design Network Switch, Limited Lifetime Protection

Tenda TEG1016G, 16 Port Gigabit Switch, Unmanaged Rackmount Ethernet Switch with Traffic Optimization, Plug & Play, Fanless Quiet & Metal Design Network Switch, Limited Lifetime Protection

Tenda

Tenda TEG1016D, 16-Port Gigabit Switch, Unmanaged Desktop Network Hub, Office Ethernet Switch, Sturdy Metal, Fanless, Traffic Optimization, Limited Lifetime Protection

Tenda TEG1016D, 16-Port Gigabit Switch, Unmanaged Desktop Network Hub, Office Ethernet Switch, Sturdy Metal, Fanless, Traffic Optimization, Limited Lifetime Protection

Tenda

Legrand On-Q WP3406WH 6 Port Keystone Single Gang Wall Plate, Supports Keystone Insert, Screw-In Plastic, White

Legrand On-Q WP3406WH 6 Port Keystone Single Gang Wall Plate, Supports Keystone Insert, Screw-In Plastic, White

On-Q

StarTech.com 8 Outlet Horizontal 1U Rack Mount PDU Power Strip for Network Server Racks - Surge Protection - 120V/15A - w/ 6ft Power Cord (RKPW081915)

StarTech.com 8 Outlet Horizontal 1U Rack Mount PDU Power Strip for Network Server Racks - Surge Protection - 120V/15A - w/ 6ft Power Cord (RKPW081915)

StarTech.com

TP-Link TL-SF1008P, 8 Port 10/100Mbps PoE Switch, 4 PoE+ Ports @66W, Desktop, Plug & Play, Sturdy Metal Casing, Fanless, Extend & Priority Mode, PoE Auto Recovery

TP-Link TL-SF1008P, 8 Port 10/100Mbps PoE Switch, 4 PoE+ Ports @66W, Desktop, Plug & Play, Sturdy Metal Casing, Fanless, Extend & Priority Mode, PoE Auto Recovery

TP-Link

TP-Link 16 Port 10/100Mbps Fast Ethernet Switch , Desktop or Wall-Mounting , Plastic Case Ethernet Splitter , Unshielded Network Switch , Plug and Play , Fanless Quiet , Unmanaged (TL-SF1016D)

TP-Link 16 Port 10/100Mbps Fast Ethernet Switch , Desktop or Wall-Mounting , Plastic Case Ethernet Splitter , Unshielded Network Switch , Plug and Play , Fanless Quiet , Unmanaged (TL-SF1016D)

TP-Link

GEARit Cat 6 Ethernet Cable Pack - 10-Pack 7 ft Cat6 Ethernet Patch Cables | RJ45 Network Patch Cable, 10 Gbps Snagless Gold-Plated Connectors - Ethernet Cable Cat 6 for PC, TV, Router - Blue

GEARit Cat 6 Ethernet Cable Pack - 10-Pack 7 ft Cat6 Ethernet Patch Cables | RJ45 Network Patch Cable, 10 Gbps Snagless Gold-Plated Connectors - Ethernet Cable Cat 6 for PC, TV, Router - Blue

GEARit

Legrand - OnQ 1 Port Wall Plate, Single Gang Wall Plate, High-Impact, Flame Retardant Plastic Screw In Wallplate, White, 25 Count, WP3401WH25

Legrand - OnQ 1 Port Wall Plate, Single Gang Wall Plate, High-Impact, Flame Retardant Plastic Screw In Wallplate, White, 25 Count, WP3401WH25

On-Q

TRENDnet 24-Port Unmanaged Gigabit GREENnet Desktop Switch, Ethernet Network Switch, 24 x 10-100-1000 Gigabit Ethernet RJ-45 Ports, 48Gbps Switching Capacity, Lifetime Protection, Black, TEG-S24DG

TRENDnet 24-Port Unmanaged Gigabit GREENnet Desktop Switch, Ethernet Network Switch, 24 x 10-100-1000 Gigabit Ethernet RJ-45 Ports, 48Gbps Switching Capacity, Lifetime Protection, Black, TEG-S24DG

TRENDnet

TRENDnet - TEG-S16DG 16-Port Unmanaged Gigabit GREENnet Desktop…

Featured in Comparisons

Best High‑Port‑Count Network Hubs (16 Ports or More)

Best High‑Port‑Count Network Hubs (16 Ports or More)

roundup

Best Rackmount Network Switches

Best Rackmount Network Switches

roundup

User Reviews

Please sign in to leave a review

Sort by:

No reviews yet. Be the first to review!

4.7

(1,268 reviews)

$54.99$62.9913% off

Track Price on BigBangPrice

Get notified when the price drops. Track this product on BigBangPrice, our price tracking partner.

TEG1016DCurry16-Port 3 YEARS

Network Hubs Network Switches

✓Compact 1U (13‑inch) form factor fits both desktop and rack‑mount installations, saving space in small network closets.

✓Supports full‑duplex 2000 Mbps transmission per port, ensuring stable high‑bandwidth performance for IP cameras.

Cons

✗Unmanaged design lacks VLAN, QoS, and LACP features, limiting advanced network segmentation and traffic management.
✗No Power over Ethernet (PoE) support, requiring external injectors for powered devices such as IP cameras.
✗Firmware updates are not clearly documented, and older hardware revisions (v6) have been discontinued.
✗Maximum power consumption of only 12 W may be insufficient for future expansion requiring higher power budgets.

Expert Opinion

Professional sources are limited, but manufacturer and retailer descriptions highlight the TEG1016D’s reliability for surveillance and SME networks, emphasizing its 2000 Mbps duplex speeds, robust 6 kV lightning protection, and fanless silent design as key selling points.

How It Compares

vs. TP‑Link TL‑SG1016D

Advantages

✓Similar 32 Gbps switching capacity and 16 Gigabit ports
✓Fanless design for silent operation

Disadvantages

✗Generally does not include built‑in lightning protection
✗Slightly larger chassis (≈440 mm width)

Choose Tenda for superior surge protection and a smaller footprint; choose TP‑Link if size is less critical and price is the primary factor.

vs. NETGEAR GS116

Advantages

✓Comparable 16‑port Gigabit performance and fanless operation
✓Well‑known brand reputation and support

Disadvantages

✗Typically lacks the 6 kV lightning protection found on Tenda
✗May have a larger physical footprint

Tenda is preferable for installations exposed to electrical surges, while NETGEAR is a solid alternative when brand support outweighs the need for surge protection.
