Ubiquiti NanoBeam ac Gen2 — Review & Specs | Pricepect | Pricepect

Home Network BridgesUbiquiti NanoBeam ac Gen2

Ubiquiti NanoBeam ac Gen2 — image 1

Ubiquiti Networks

Ubiquiti NanoBeam ac Gen2

Expert Review Analysis

The Ubiquiti NanoBeam 5AC Gen2 is a compact 5 GHz outdoor wireless bridge that integrates a high‑gain 19 dBi directional antenna with an airMAX ac radio, delivering up to 450 Mbps over distances beyond 10 km. Its lightweight design, low power draw, and rugged enclosure make it ideal for point‑to‑point and point‑to‑multipoint backhaul in demanding environments.

✓ Best for: Wireless ISPs for point‑to‑point backhaul, remote site connectivity requiring 10+ km links, network extensions across large distances, deployments in RF‑dense or extreme weather environments, and budget‑conscious enterprises needing a cost‑effective outdoor CPE with passive PoE.✗ Not ideal for: Scenarios needing omnidirectional coverage, indoor or short‑range Wi‑Fi access, environments with heavy foliage or obstacles blocking line‑of‑sight, users requiring Wi‑Fi 6/6E features, or applications demanding high onboard processing or storage.

Pros

✓Extremely compact and lightweight design with the highest gain-to-footprint ratio in its class
✓High directional 19 dBi antenna reduces noise and interference, providing superior signal quality in RF‑dense environments

Price History

Current

$95.99

Average

$102.84

Lowest

$84.99

Highest

$179.00

Good Deal — 7% below average

Price trend (90d):0.0%

Best Seller Rank History

Now#124Best#54Worst#224 +100

Lower = better sales rank

Rating Trend

Rating4.6/ 5Reviews563+47 reviews

Specifications

Accessories

Included AccessoriesPoE Adapter, Pole-mount kit

Design

Height96.52 mm mm

Width241.30 mm mm

Length226.06 mm mm

Weight907.18 g g

Enclosure MaterialOutdoor UV-stabilized plastic

Features

3-axis Ball Joint MountYes

UISP-readyYes

Dedicated Wi-Fi Management RadioYes

General

BrandUbiquiti Networks

ManufacturerUbiquiti

Model NameNBE-5AC-Gen2-US

Release Date2018-01-01

Warranty1 year

Network

Wireless Standard802.11ac

Frequency5 GHz

Frequency Range5.150 - 5.875 GHz

Data Rate (5GHz Radio)450 Mbps Mbps

Channel Sizes PtP10, 20, 30, 40, 50, 60, 80 MHz

Performance

Processor ModelAtheros MIPS 74Kc

Processor Clock Speed720 MHz MHz

RAM Size128 MB MB

Flash Size8 MB MB

Memory TypeDDR2

Ports

Ethernet Ports2 (10/100/1000 Gigabit), 1 PoE out

Wi-Fi Management RadioYes

Power

Power Supply Voltage24 V V

Power Supply Current0.5 A A

Supported Voltage Range20–27 V DC

Max Power Consumption8.5 W W

Output Power25 dBm dBm

Sensors

ESD/EMP ProtectionAir: ±24 kV, Contact: ±24 kV

Research Sources

flyteccomputers.com

netwifiworks.com

insight-distribution.ph

Similar Products

Ubiquiti NanoBeam 2AC airMAX ac ...

TP-Link Omada Point to Point Wireless Bridge Outdoor - 5GHz, 867Mbps, PtP&PtMP, 1km Range, 3 Gigabit Ports, PoE or DC Powered, IP65 Weatherproof, Preconfigured, Plug&Play(EAP211-Bridge KIT)

TP-Link Omada Point to Point Wireless Bridge Outdoor - 5GHz, 867Mbps, PtP&PtMP, 1km Range, 3 Gigabit Ports, PoE or DC Powered, IP65 Weatherproof, Preconfigured, Plug&Play(EAP211-Bridge KIT)

TP-Link

WAVLINK N300 Wireless Outdoor Ac...

KORYCE Universal Wireless Bridge Bracket Mount, 2-Pack J Pole Mounts, 180 Adjustable Wall-Mounted Mount for Outside Antenna Starlink, Outdoor Bracket for AP Access Point Client CPE

KORYCE Universal Wireless Bridge Bracket Mount, 2-Pack J Pole Mounts, 180 Adjustable Wall-Mounted Mount for Outside Antenna Starlink, Outdoor Bracket for AP Access Point Client CPE

KORYCE

Wireless Bridge NSM5 Pre-Configu...

Adalov WiFi 6 Wireless Bridge, Dual Band Gigabit WiFi Bridge with 5KM Long Range, 2.4G/5.8G, Compatible with Starlink, Plug & Play, Point-to-Point Wireless Bridge for Barn Garage Farm, IP65

Adalov WiFi 6 Wireless Bridge, Dual Band Gigabit WiFi Bridge with 5KM Long Range, 2.4G/5.8G, Compatible with Starlink, Plug & Play, Point-to-Point Wireless Bridge for Barn Garage Farm, IP65

AdaLov

Wireless Bridge NBE-5AC-GEN2 PRE...

54V Power Adapter for Ubiquiti U...

Wireless Bridge LOCO5AC Pre-Conf...

Pre-Configured Wireless Bridge L...

Featured in Comparisons

Best PoE-Powered Network Bridges

Best PoE-Powered Network Bridges

roundup

Best 5 GHz Network Bridges

Best 5 GHz Network Bridges

roundup

Ubiquiti NanoBeam ac Gen2 vs Vonets VAP11AC

User Reviews

Please sign in to leave a review

Sort by:

No reviews yet. Be the first to review!

4.6

(563 reviews)

$95.99

Track Price on BigBangPrice

Get notified when the price drops. Track this product on BigBangPrice, our price tracking partner.

NBE-5AC-GEN2-USWhite 1 year

Network Bridges

✓

Supports 10+ km point‑to‑point links delivering up to 450 Mbps throughput using airMAX ac and 256QAM

✓Low power consumption of only 8.5 W enables passive PoE deployment and reduces operating costs

✓Robust outdoor UV‑stabilized plastic housing and wind survivability rating of 200 km/h (125 mph) for harsh weather

✓Integrated radio and antenna with 3‑axis ball‑joint mount simplifies alignment without tools

✓Dual Gigabit Ethernet ports with PoE out and dedicated Wi‑Fi management radio for out‑of‑band administration

Cons

✗Directional antenna design limits use to point‑to‑point or focused point‑to‑multipoint scenarios, unsuitable for omnidirectional coverage
✗Requires clear line‑of‑sight between endpoints; performance degrades significantly with obstacles or foliage
✗Only supports 802.11ac Wi‑Fi standard, lacking newer Wi‑Fi 6/6E features and associated performance gains
✗Limited onboard memory (128 MB RAM, 8 MB flash) restricts advanced features and future firmware expansion
✗Maximum output power of 25 dBm may be insufficient for very long links in high‑interference environments

From Expert Reviews

Praised by Experts

✓Innovative integrated radio‑antenna design maximizes gain while minimizing footprint, praised by editors
✓Directional beamwidth provides excellent noise immunity, highlighted as a key advantage in RF‑congested sites
✓450 Mbps throughput with 256QAM modulation delivers triple the speed of standard airMAX products
✓3‑axis ball‑joint mount and included pole‑mount hardware simplify installation and alignment
✓Rugged UV‑stabilized plastic enclosure and 200 km/h wind rating ensure reliability in extreme outdoor conditions

Expert Opinion

Professional reviewers commend the NanoBeam 5AC Gen2 for its innovative all‑in‑one design that packs a high‑gain 19 dBi antenna and airMAX ac radio into a tiny enclosure, delivering up to 450 Mbps and exceptional noise immunity in RF‑dense environments. They highlight the easy alignment via a 3‑axis ball joint, low 8.5 W power draw for passive PoE, and the rugged construction rated for 200 km/h winds as strong points for outdoor deployments.

How It Compares

vs. NanoBeam 2AC 13dBi

Advantages

✓Higher antenna gain (19 dBi vs 13 dBi)
✓Much faster data rate (450 Mbps vs none)
✓Operates on 5 GHz band with more spectrum availability

Disadvantages

✗Same physical dimensions and weight despite lower performance
✗Higher power consumption (8.5 W vs 7.5 W)
✗Lower frequency (2 GHz) offers better foliage penetration but less throughput

Choose the NanoBeam 5AC Gen2 for maximum throughput and long‑range performance; choose the NanoBeam 2AC when lower‑frequency penetration is more critical than speed.

vs. NanoBeam M5 16dBi

Advantages

✓More compact form factor (140 × 140 × 54 mm)
✓Lower power consumption (6 W)

Disadvantages

✗Lower antenna gain (16 dBi vs 19 dBi)
✗Older 802.11n standard limits data rates
✗No 5 GHz high‑throughput capability

Select the NanoBeam 5AC Gen2 for highest gain and 5 GHz high‑speed links; select the NanoBeam M5 for space‑constrained or low‑power installations where performance demands are modest.

Hardware

ProcessorAtheros MIPS 74Kc, 720 MHz

Memory128 MB DDR2 RAM, 8 MB flash

Environmental

Operating Temperature Range-40 °C to 80 °C

Wind Survivability200 km/h (125 mph)

Protection

ESD/EMP ProtectionAir ±24 kV, Contact ±24 kV

Dimensions & Weight

Height3.8 Inches

Width9.5 Inches

Depth8.9 Inches

Weight2.0 Pounds
