Name: BTF-LIGHTING DR03W
Brand: Btf-lighting
SKU: B0DB5P7LBC
Price: 24.99 USD
Availability: InStock
Rating: 4.2 (103 reviews)

Expert Review Analysis

The DR03W is a Wi‑Fi‑enabled RGB SPI controller for addressable LED strips, supporting up to 720 pixels and offering control via the Tuya app, voice assistants, Bluetooth, and a 2.4 GHz RF remote. It works with a broad range of addressable ICs and provides extensive lighting effects and color calibration.

✓ Best for: DIY LED enthusiasts, smart‑home users, and small‑to‑medium installations that need segment‑level color control and integration with voice assistants. Ideal for decorative ambient lighting, accent lighting in smart homes, and entertainment setups requiring up to 720 addressable pixels.✗ Not ideal for: Projects that rely on standard PWM RGB/RGBW strips, very large installations requiring more than 12 A input current, or environments that need longer‑range remote control beyond 30 meters.

Pros

✓Supports up to 720 addressable LED pixels for extensive lighting projects
✓Multiple control options including WiFi, Bluetooth, 2.4 GHz RF remote, and major voice assistants
✓

Best Seller Rank History

Now#414Best#348Worst#647 -1

Lower = better sales rank

Rating Trend

Rating4.4/ 5Reviews56+-47 reviews +0.20

Specifications

Connectivity

WiFi2.4 GHz

Bluetooth VersionSupported

WiFi Band2.4 GHz only (5 GHz not supported)

Controls

Control MethodsTuya app, voice assistants (Alexa, Google Home, Mijia, Yandex, Xiaodu), RF remote

RF Remote Range30 m m

Supported RF RemotesWR01RF, RC03RFB, RC04RFB, RC05RB

Multi-Zone ControlSupported

Voice Assistant SupportAlexa, Google Home, Mijia, Yandex, Xiaodu

Design

Weight68 g g

Length107.6 mm mm

Width38.4 mm mm

Height22 mm mm

Features

Color CalibrationAdjustable core type and RGB sequence via Tuya app

Dynamic Effects44 default modes, 10+ custom modes (jumping, breathing, flickering, flowing, rainbow, meteor)

General

BrandBtf-lighting

ManufacturerBTF-LIGHTING Technology Co., Limited

ModelDR03W

ColorWs2811/Ws2812b etc RGB

SizeSPI Controller Only

Lighting

Maximum Pixels720

Adjustable RangeRGB: 20–720 ICs; RGBW: 20–700 ICs; RGBCCT: 20–450 ICs

Power

Input VoltageDC 5V–24V

Input CurrentMax 12 A A

Output Signal5V SPI

Maximum Current Output15 A A

Software

Supported AppsTuya app, Smart Life app

Compatibility

Adjustable Pixel RangeRGB: 20–720 ICs; RGBW: 20–700 ICs; RGBCCT: 20–450 ICs

Signal

Output Signal Type5 V SPI

Dimensions & Weight

Weight0.14991433816 pounds
